Truck Number:
- S5722 Retail Unit
Chassis:
- 2026 Spartan custom chassis with an EMFD flat-roof crew cab
- Cummins X12 11.8L diesel engine rated at 500 HP and 1,700 lb-ft of torque
- Allison EVS 4000 automatic transmission
- 23,000 lb front GAWR and 35,000 lb rear GAWR
Body:
- 480 U.S. gallon UPF water tank with an integrated 20 U.S. gallon Class A foam cell
- 30-cubic-foot hose bed positioned ahead of the turntable
- Nine main equipment compartments with additional wheel-well storage
Pump & Aerial:
- Waterous CSU single-stage fire pump rated at 1700 GPM
- 77-foot three-section rear-mount aerial ladder
- 71-foot 5-inch horizontal reach
- Operating range from -6 degrees to +72 degrees
- 360-degree continuous aerial rotation
- TFT electric master-stream nozzle with an adjustable flow range of 300–1,500 GPM
Highlights:
- Rear H-style stabilizers with an 18-foot spread
- Positional waterway with Rescue and Water Tower operating modes
- Loadminder real-time aerial load-sensing system with overload warnings
- Two-way communication system between the ladder tip and turntable
- Whelen LED aerial-tip spotlights
- 6,000-watt Harrison hydraulic generator
- Fully enclosed ground-ladder storage
- Extensive compartment and equipment storage
